View the dimensions and additional features of our range of medium-duty Accuride drawer slides.
Struggling to select the right drawer runner? Read our information page for help and guidance.
See our other range of drawer runners:
| Slide Series | Load Rating up to (KG) | Extension (%) | Slide Thickness (mm) | Slide Height (mm) | Front Disconnect | Hold-in | Hold-out | Lock-in | Lock-out | Soft-close | Two-way Travel | Optional Brackets | Additional Features |
| 5417EC | 55 | 100 | 17.5 | 54 | Soft close on last 45mm of closing | ||||||||
| 2907 | 55 | 100+ | 9.6 | 41.1 | |||||||||
| 5517-50 | 55 | 100+ | 17.5 | 53.4 | Bayonet mounting, vertical mounting only | ||||||||
| 3320-50 | 60 | 100+ | 12.7 | 50.8 | Bayonet mounting | ||||||||
| DS2028 | 60/65 | 75 | 9.5 | 35.34 | High-grade stainless steel, ideal for environments subject to corrosion | ||||||||
| 0204 | 65 | 75 | 9.5 | 35.3 | |||||||||
| DS0330 | 65/80 | 100 | 19.1 | 35.3 | High-grade stainless steel | ||||||||
| 3932 | 68 | 100 | 12.7 | 51.0 | |||||||||
| 3932EC | 68 | 100 | 12.7 | 51.0 | |||||||||
| 3301 | 68 | 100+ | 12.7 | 50.8 | Electronic enclosure slides | ||||||||
| 3306 | 68 | 100+ | 12.7 | 50.8 | Fixing hardware included, suitable for flat mounting | ||||||||
| 3307 | 68 | 100+ | 12.7 | 50.8 | Fixing hardware included | ||||||||
| 3308 | 68 | 100+ | 12.7 | 50.8 | Fixing hardware included | ||||||||
| 0305 | 70 | 100+ | 19.1 | 35.3 | High-grade stainless steel available | ||||||||
| DS3557 | 90 | 100+ | 12.7 | 51.6 | Pinch free, spring disconnect | ||||||||
| DS5334 | 90 | 100+ | 19.1 | 53 | High-grade stainless steel, ideal for environments subject to corrosion, not suitable for flat mounting | ||||||||
| 5417 | 90/100 | 100+ | 17.5 | 54 | Suitable for horizontal mounting |
